3 phase electricity supply – 415V, 32A, 5 pin Neutral & Earth.

Automation

200Kg Payload

800mm Basket diameter

600mm Working Height

Pre-Heat Facility

CE Approved Equipment

Multiple substrates can be cleaned

Multiple NCH Chemistries suited to different substrates

140 Litres maximum fill level

3.6 to 5.5 Bar and 150 litres per minute

We recommend and pre-set the machine to operate at 60 degrees C

Machine can wash for cycles of between 1 and 60 minutes

Three Options;

Our patented Chemistry Storm1 at 4 Litres per fill

ADS Power Clean at 4 Kg Tub per fill

Aviation approved Super Bee at 5 Litres per fill

1. Ensure the machine and chemistry is up to operating temperature
2. Load the parts into the machine, spread them evenly around the basket to spread the weight distribution
3. Close the lid
4. Press the start button
5. Machine will automatically stop at end of the wash cycle or when you hit the stop button

A little foaming is perfectly normal, but some contaminants can cause excess foaming. To prevent this add 25ml of NCH Cease Foam NS, available from your NCH representative

The machine has the facility to be pre-programmed, to allow the chemistry to pre-heat up to temperature before a working shift pattern starts. For example if parts cleaning starts at 8 am, the machine can be pre-programmed to switch on and begin to heat up at 6:30 am, etc.

Ensure you have power to the machine (is there a display on the digital control panel screen) and that the machine is up to temperature (the ‘Ready to Start’ button is illuminated)

Is there sufficient liquid in the sump, minimum fill level to operate is 90 Litres (if the low level light is illuminated then add more liquid to the sump to reach at least the minimum level).

Refer to the user manual to troubleshoot the machine. If machine still does not start then contact NCH.
